Mini Plus DNA Horizontal Gel Electrphoresis RE001PLUS

DNA Electrophoresis. Gel electrophoresis separates DNA fragments by size in a solid support medium (an Agarose gel.)

Add to List

DNA Electrophoresis. Gel electrophoresis separates DNA fragments by size in a solid support medium (an Agarose gel.)



·         Minimum Sample               10 wells

·         Maximum sample               40 wells

·         Gel Size                             10x12cm

·         Buffer Volume                    480ml

·         Comb slots distance           3.5cm

·         Voltage                               75-120V



Products Code

Product

Size

Quantity

RE001- PLUS-UT

Mini Plus horizontal gel running tank 13.5 x 26 x 6cm

480ml

1

RE001-PLUS-RT

Gel Casting Tray (Gel running try) with two slots

10X12cm

1

RE001- PLUS -CT

Gel caster try with silicon mat

12x17cm

1

RE001- PLUS -W

0.2mm thick platinum wire

12cm

1pair

RE15C

Power leads with 4mm output connectors

1.5 meter

1pair

RE001-PLUS–C10-1

10Well comb, teeth size 8mm/2.5mm teeth space

1mm

2

RE001- PLUS- C16-1

16 Well comb, teeth size 3.5mm/2mm teeth space

1mm

2

RE001- PLUS-C10-1.5

10well comb, teeth size 8mm/2.5 teeth space

1.5mm

2

RE001- PLUS C16-1.5

16 Well comb ,3.5mm//2mm teeth space

1.5mm

2

Code

Product

Size

Quantity

RE001-PLUS-RT

Gel Casting Tray (Gel running try)  with two slot

10x12cm

1

RE001-PLUS-CT

Gel caster try with silicon  mat

12x17cm

1

RE001- PLUS -WB

0.2mm thick platinum wire Black

12cm

1

RE001- PLUS -WR

0.2mm thick platinum wire Red

12cm

1

RE15C

Power leads with 4mm output connectors

1.5 meter

1pair

RE001-PLUS–C10-1

10Well comb, teeth size 8mm/2.5mm teeth space

1mm

1

RE001- PLUS- C16-1

16Well comb, teeth size 3.5mm/2mm teeth space

1mm

1

RE001-PLUS-C20-1

20Well comb ,teeth size 3mm/1.5mm teeth space

1mm

1

RE001-PLUS-C10-1.5

10Well comb, teeth size 8mm/2.5mm teeth space

1.5mm

1

RE001-PLUS- C16-1.5

16Well comb, teeth size 3.5mm/2mm teeth space

1.5mm

1

RE001-PLUS-C20-1.5

20Well comb ,teeth size 3mm/1.5mm teeth space

1.5mm

1
